Model No.: JKD-838W
●Communication protocol: WiFi-2.4GHz
●Supply voltage: AC 100-240V, 50Hz
●Power consumption: Max 5W
●Standard: EN50194-1:2009
●Gas detected: CH4
●Alarm concentration: ＞8.0%LEL(4000ppm)
●Operating environment: Temperature: -10℃~55℃
Relative humidity: 95% No condensing
Atmospheric pressure: 86kPa~106kPa, Indoor use type
●Sampling Method: Natural diffusion
●Alarm Method: Sound, Lighting Alarm
●Alarm volume: ≥85dB at 1m
●Sensors: Catalytic sensor
●Max sensor lifetime: 5 years
●Weight: around 200g
●Size: L120×W75×H40mm
Product Categories
Need consultation?
Protect your home and business from natural gas leaks with our Smart 2.4GHz WiFi Gas Detector, designed for reliable methane (CH₄) detection and real-time remote monitoring. Equipped with a high-performance catalytic sensor and compatible with the Tuya Smart APP, this intelligent gas detector immediately sends alarm notifications to your smartphone whenever a gas leak is detected, allowing you to respond quickly even when you are away.
Designed specifically for the European market, the WiFi Gas Detector JKD-838W complies with EN50194-1:2009 requirements and is CE certified. Every unit is tested by the official SGS laboratory, ensuring consistent quality, stable performance, and dependable safety protection. It is an excellent solution for OEM brands, distributors, wholesalers, and smart home system integrators.
The detector connects directly to your 2.4GHz WiFi network without requiring additional gateways, making installation simple and convenient.
Compatible with both Tuya Smart and Smart Life applications, users can receive instant gas leak notifications, monitor device status remotely, perform self-checks, and manage home safety from anywhere.
Built with a reliable catalytic gas sensor, the detector continuously monitors methane concentrations and quickly activates an alarm when gas levels exceed 8% LEL (4000 ppm).
When a gas leak is detected, the detector activates both a high-intensity sound alarm of ≥85dB at 1 meter and a bright LED warning, ensuring occupants are alerted immediately.
Manufactured according to EN50194-1:2009, the detector carries CE certification and has been tested by SGS, providing confidence for European importers and distributors.
The high-quality catalytic sensor offers a maximum service life of 5 years, ensuring long-term stability with minimal maintenance.
Powered by AC 100–240V, the detector plugs directly into a wall outlet, making installation quick without complicated wiring.
| Working voltage: | AC 100-240V, 50Hz |
| Standby current: | <200uA |
| Alarm currect | <150mA |
| Warming time: | 3 minutes |
| Pressure: | 86kPA~106kPA |
| Inspection gas: | natural gas and liquefied petroleum gas； methane and propane; |
| Detecting: | Gas Alarm over 6%LEL,Keep alarming over 25%LEL |
| User environment: | temperature: -10°C~55°C ;Relative humidity:<95% without crystallization; |
| Alarm type : | sound and light alarming |
| Alarming volume: | >80dB (at three meter directly in front) |
| Sensor: | semiconductor sensor |
| Weight: | about 200g |
| Dimensions: | 120*75*40mm |
| Shell protection grade: | IP30 |
|
Certificates |
EN50194-1:2009,related to CE Directive(s) R305/2011 |
| SGS | |
| IEC62321-1:2013 | |
| EN55014-1:2017 |
This machine has been calibrated before leaving the factory. You only need to clean the housing of the detector frequently during use to ensure that the hole in the front of the detector is not blocked by dirt or dust .
Basically, no other maintenance is required. When cleaning the detector housing, please use a clean soft brush or dry flannel to wipe, do not use detergent, bleaching powder or polish.
During the working process of the detector, a self-checking test is carried out every minute.
Under normal use, the detector can operate for 5 years. When the detector sends out an end-of-life signal (the buzzer beeps once every minute), the detector must be replaced. If the detector reaches the end of its life, please follow local regulations for disposal.
This product is designed for indoor use only. Please avoid the detector from being exposed to rain or moisture, and avoid dropping the detector. Do not knock, open or modify the detector, otherwise it may cause the product to malfunction.
Covering the detector, improper use or maintenance may reduce or lose the detection function.
What certificates do you have on LPG/LNG gas Alarm?
We have full CE/RoHS certificates asEN50194-1:2009,related to CE Directive(s) R305/2011,EN62368-1:2014+A11:2017,etc
How you make sure gas alarm’s calibration is set?
We have gas calibrators both for sample and mass production,The calibration team have 5 employees aim to make sure the alarms are set.
What kind of sensor do you apply in gas alarms?
Most of our carbon monoxide alarm use semiconductor sensors,3~5 years life,5~7 years life and 10 years life,We have more advanced sensor applied in industrial gas detector.
What language you can offer for VOICE gas alarm?
Standard language is English,We have experience make Japanese,Spanish,Germany,Russia,etc.You can offer us some audio data if you have.
Can I make my own logo and color box?
Sure,OEM/ODM are welcome but need MOQ at 500pcs,All cost are pree include logo printing,color box designning or even language customization.
What is your lead time?
Sample can be ready in 3 days.Mass production need one week when quantity lower 2000pcs,we need add more three days if you have OEM requirement.
What if I need return the goods,Who pay the shipping fee?
All our products enjoy 12 months’ quality warranty.In this period, We here ensure you that goods can be returned and we will cover the shipping fee if the alarms not working because of the less in quality.
